Axial Panel Mount Contact Pressure Gauge with Front Flange Electric Switch Industrial Monitoring Instrument

Product Overview

This axial panel mount contact pressure gauge is designed for industrial control systems requiring accurate pressure monitoring and electrical alarm switching. The front flange structure allows easy installation on control panels and machinery equipment.

Key Features

• Axial panel mount design with front flange installation
• Electric contact switch for alarm/control output
• Mechanical Bourdon tube pressure measurement system
• Stainless steel or brass wetted parts options
• Stable and reliable industrial performance
• Suitable for automation and control systems
• Easy installation on control cabinet panels
• High vibration resistance structure
• Adjustable pressure set points (optional)
• Clear and durable dial display

Technical Specifications

Applications

• Industrial automation systems
• Pump pressure control systems
• Hydraulic system monitoring
• Control cabinet instrumentation
• HVAC system pressure monitoring
• Chemical process equipment
• Water treatment systems
• Industrial safety alarm systems

Working Principle

Pressure enters the Bourdon tube, causing elastic deformation. This movement drives the pointer and simultaneously activates electrical contacts when preset limits are reached, enabling automatic alarm or control signals.

FAQ

What is a contact pressure gauge used for?

It is used for pressure monitoring and automatic alarm switching in industrial systems.

What is the advantage of axial panel mounting?

It allows easy installation directly on control panels or equipment surfaces.

Can it be used in automation systems?

Yes, it is widely used in industrial automation and safety control systems.
