63mm Stainless Steel Panel Mount Pressure Gauge 38bar BSPT

Product Introduction

The 63mm stainless steel panel mount pressure gauge is designed for industrial pressure measurement applications requiring reliable mechanical indication and convenient front panel installation.  The instrument utilizes a Bourdon tube measuring system to provide accurate pressure indication in refrigeration systems, HVAC equipment and general industrial machinery.

Key Features

• 63 mm (2.5 inch) dial size
• Pressure range: 38 Bar
• Front flange panel mounting design
• BSPT threaded process connection
• Stainless steel case construction
• Bourdon tube measuring system
• Clear analog pressure indication

Technical Specifications

Applications

• Commercial refrigeration systems
• HVAC pressure monitoring equipment
• Air compressor control panels
• Industrial machinery and process equipment
• Mechanical engineering applications
• Equipment requiring panel-mounted pressure indication

Product Advantages

1. Convenient Panel Installation

The front flange mounting configuration simplifies installation and improves readability on control panels and operator interfaces.

2. Durable Stainless Steel Construction

The stainless steel housing enhances durability and supports long-term use in industrial environments exposed to moisture and demanding operating conditions.

3. Reliable Mechanical Performance

The Bourdon tube measuring mechanism provides direct pressure indication without requiring electrical power.

4. Compact Yet Easy to Read

The 63mm dial offers an effective balance between installation flexibility and visibility for daily operation.

Working Principle

As process pressure enters the Bourdon tube, the elastic pressure element deforms proportionally to the applied pressure. The resulting movement is transmitted through the internal mechanical linkage system to rotate the pointer across the dial, providing real-time visual pressure indication.

FAQ

What is a panel mount pressure gauge?

A panel mount pressure gauge is designed for installation through equipment panels using front flanges or mounting brackets.

What does BSPT mean?

BSPT refers to British Standard Pipe Taper thread, commonly used in industrial pressure measurement applications.

Can this pressure gauge be used in refrigeration systems?

Yes. Panel mount pressure gauges are frequently used in refrigeration and HVAC applications requiring local pressure indication.
