40mm Mini Radial High Pressure Gauge, 0–170 Bar / 0–2500 PSI

Product Overview

The 40mm Mini Radial High Pressure Gauge is designed for compact mechanical pressure measurement and local pressure indication in compatible equipment and instrumentation systems. Its 40mm format combines a compact gauge size with a high pressure measuring range of 0–170 bar / 0–2500 psi.

The radial configuration provides a pressure gauge arrangement for equipment where the pressure connection is positioned below the dial. The compact 40mm format can be considered for installations where available space is limited and a mechanical pressure indicator is required.

With a specified range of 0–170 bar / 0–2500 psi, this gauge is intended for compatible high-pressure measurement applications. The actual gauge selection should be based on the system pressure, measured medium, connection specification and operating conditions.

Technical Specifications

Applications

This 40mm high pressure gauge can be considered for compatible industrial equipment, machinery and pressure systems requiring local mechanical pressure indication within the specified measuring range.

• High-pressure equipment monitoring
• Industrial machinery pressure indication
• Mechanical pressure measurement systems
• Industrial instrumentation
• Compact equipment pressure monitoring
• High-pressure system indication

The suitability of the gauge should be evaluated according to the measured medium, operating pressure, temperature, connection requirements and other conditions of the application.

Product Advantages

Compact 40mm Format

The 40mm dial provides a compact pressure indication format for equipment where installation space is limited. The smaller gauge format can be useful when a larger dial is not required by the installation layout.

High Pressure Measurement Range

The specified pressure range is 0–170 bar / 0–2500 psi, providing a high pressure measurement option for compatible systems operating within this range.

Radial Configuration

The radial configuration provides a pressure connection arrangement suitable for compatible equipment layouts where the connection is positioned below the gauge.

Mechanical Pressure Indication

As a mechanical pressure gauge, the instrument provides local pressure indication directly on the dial. It can be considered where a local mechanical pressure reading is required rather than a digital display.

Why Choose a 40mm High Pressure Gauge?

Gauge size and pressure range are two important factors when selecting a mechanical pressure gauge. A 40mm gauge provides a compact format, while the 0–170 bar / 0–2500 psi range is intended for higher-pressure measurement requirements.

For equipment with limited installation space, a compact gauge can be considered when the available mounting area does not require a larger dial. The final selection should also consider readability, connection position and the actual operating pressure of the system.

FAQ

What is the diameter of this pressure gauge?

The gauge has a 40mm dial size.

What is the pressure range?

The specified pressure range is 0–170 bar / 0–2500 psi.

Is this a high pressure gauge?

Yes. The product is specified as a high pressure gauge with a maximum listed measuring range of 170 bar / 2500 psi.

What does radial pressure gauge mean?

A radial pressure gauge refers to a configuration in which the pressure connection is arranged below the gauge. The exact connection dimensions and thread specification should be checked from the product datasheet.
