| Place of Origin: | Anhui, China |
| Brand Name: | XK Gauge |
| Certification: | CE, ISO |
| Model Number: | YN63 |
Professional axial pressure and temperature combination gauge featuring a 63 mm dial with 1/4" NPT connection, designed for accurate measurement in the 0–6 bar range. Built with a robust 304 stainless steel housing for superior durability in demanding industrial environments.
| Parameter | Value |
|---|---|
| Dial Size | 63mm |
| Connection | 1/4" NPT |
| Pressure Range | 0–6 bar |
| Type | Axial combination gauge |
| Measurement | Pressure and temperature |
| Accuracy Class | 1.6 / 2.5 (customizable) |
| Material | 304 Stainless Steel |
| Brand | XK Gauge or Customized |
| Model Number | YN63 |
| Certification | CE, ISO |
| Place of Origin | Anhui, China |
Durable 304 stainless steel housing ensures long-term corrosion resistance and structural integrity
Dual-function design combines pressure and temperature measurement in one compact 63mm dial
Axial mount configuration with standard 1/4" NPT connection simplifies installation in tight spaces
CE and ISO certified manufacturing meets international quality and safety standards
Wide 0–6 bar pressure range suitable for diverse industrial monitoring applications
ApplicationsHydraulic and pneumatic system monitoring
HVAC and refrigeration equipment
Industrial boiler and compressor systems
Water treatment and pumping stations
Oil and gas pipeline instrumentation
General industrial process control
Customization & OEM ServiceWe offer flexible customization options to meet your specific requirements:
Dial size: 40mm, 50mm, 63mm, 80mm, 100mm available
Pressure range: customizable from 0–1 bar to 0–1000 bar
Temperature range: various thermowell options available
Connection type: NPT, BSP, BSPT, metric threads
Custom dial printing with your logo and branding
Custom packaging with private label options
MOQ: 100 PCS | Supply Ability: 50,000 PCS per month | Delivery: 3-5 days
Q: What is an axial pressure temperature combination gauge?
An axial combination gauge simultaneously displays both pressure and temperature readings on a single 63mm dial. The axial (bottom) connection design allows for easy panel mounting in control cabinets and equipment panels.
Q: What industries commonly use this gauge?
This gauge is widely used in hydraulic systems, HVAC equipment, industrial boilers, compressors, water treatment plants, and oil and gas pipeline monitoring applications.
Q: Can the pressure range and connection type be customized?
Yes, we offer full customization of pressure range (from 1 bar to 1000 bar), connection type (NPT, BSP, BSPT, metric), dial size, and even custom logo printing on the dial face.
Q: What certifications does this gauge have?
This product is CE and ISO certified, ensuring compliance with international quality and safety standards for industrial measuring instruments.
