Crimped Type Liquid Filled Pressure Gauge 63mm For Silicone Oil

Description
Size: 63mm Mount: Center Back
Pressure Range: 25 Bar Or Customized Case Material: 316 SS, 304 SS
Lens Material: Instrument Glass Bourton Tube: Phosphor Bronze
Movement: Brass Dial: Aluminum, Dual Scale
Accuracy: 1.6 Liquid: Silicone Oil, Glycerin
High Light:

Liquid Filled Pressure Gauge 63mm

,

Crimped Liquid Filled Pressure Gauge

,

Silicone Oil Pressure Gauge

2.5 Inches 25 bar Silicone Oil Filling Manometer G 1/4 Back Connection Liquid Filled Pressure Gauge

Description
Advantages of liquid filled gauges
The filling liquid dampens any pressure peaks, shocks and vibrations that occur and protects the mechanics of the pressure gauge. Thus, material fatigue and malfunction is counteracted.
A further factor – decisive for the user – is to ensure the readability of the prevailing pressure. The filling liquid causes the pointer’s motion to be limited, even under severe vibration loads. Without liquid damping, the pointer would not show the actual applied pressure, but rather move to and fro in relation to the frequency of the vibrations prevailing in the application. In the event of resonance, a deflection angle of over 180° could even occur.
Liquid filled gauges are suitable for a variety of applications, specifically processes involving shock and vibration.

Applications
For measuring locations with high dynamic pressure loads and vibrations
For gaseous and liquid media that are not highly viscous or crystallising and will not attack brass parts
Hydraulics
Compressors, shipbuilding
​​
Special features
Vibration and shock-resistant
Especially robust design
Completely from stainless steel
Scale ranges up to 0 ... 1000 bar


Specifications

Design

EN 837-1

Nominal size

63mm

Accuracy

Acc.1.6
Pressure range25 bar (customized)

Pressure limitation

40mm, 50mm, 63mm:
Steady: 3/4 x full scale value  Fluctuating: 2/3 x full scale value  Short time: full scale value
100mm:
Steady: full scale value  Fluctuating: 0.9 x full scale value  Short time: 1.3 x full scale value

Permissible temperature

Ambient: -20 ... +60 °C
Mediium: +60 °C maximum

Ingress protection

IP65

Temperature effect

When the temperature of the measuring system deviates from the reference temperature (+20 °C): max. ±0.4 %/10 K of the span

Process connection

Brass

Pressure element

Brass, C-type or helical type
MovementBrass
DialAluminium, colorful, without pointer stop pin
Black lettering
PointerAluminium
CaseStainless steel
RingStainless steel
WindowPlastic, glass, safety glass
Unit

bar, psi, kg/cm2, kPa, MPa

Thread1/4 G, BSP, PT, BSPT, NPT
OptionsOther process connection thread
Surface mounting flange
Mounting bracket


Dimensions
Crimped Type Liquid Filled Pressure Gauge 63mm For Silicone Oil 0

SizeDimensions in mmWeight in kg
abb2D1D2efGhSW
5012305555505.5-1/4"48140.15
6313325668626.5-1/4"54140.21
10015.54881.51071008301/2"87220.80
