Product Details:
|
| Size: | 63mm | Mount: | Bottom, Radial |
|---|---|---|---|
| Pressure Range: | 70 Bar Or Customized | Color: | Metallic |
| Case Material: | Stainless Steel | Window: | PC Or Glass |
| Movement: | Brass | Dial: | Aluminum |
| Accuracy: | 1.0 | Deaign: | EN837-1 |
| High Light: | Glycerin Filled Stainless Steel Pressure Gauge,Stainless Steel Glycerine Manometer,Stainless Steel Pressure Gauge 70 Bar |
||
63mm 70 bar Panel Mounting Lower Connection Stainless Steel Pressure Gauge Liquid Fillable
Description
The glycerine filling of the case protects the measuring systems against wear by pulsating pressures and mechanical vibration; at the same time it provides lubrication of the moving parts. The glycerine pressure gauges are suitable for gaseous and liquid media that do not corrode copper alloys.
Applications
Suitable for gaseous or liquid media that will not obstruct the pressure system
Machine building and plant construction
Heating and air-conditioning technology
Fire sprinkler systems
Special features
Design per EN 837-1
Nominal size 40, 50, 63, 80, 100 and 160
Scale ranges up to 0 ... 1000 bar
|
Design |
EN 837-1 |
|
Nominal size |
63mm |
|
Accuracy |
1.0 |
| Pressure range | 70 bar (customized) |
|
Pressure limitation |
Steady: 3/4 x full scale value |
|
Permissible temperature |
Ambient: -40 ... +60 °C |
|
Temperature effect |
When the temperature of the measuring system deviates from the reference temperature (+20 °C): max. ±0.4 %/10 K of full scale |
|
Process connection |
Brass |
|
Pressure element |
Brass, C-type |
| Movement | Brass |
| Dial | Aluminium, white, without pointer stop pin Black/red lettering |
| Pointer | Aluminium |
| Case | Stainless steel |
| Window | Plastic, glass |
| Options |
Other process connection thread |
Dimensions
Model M01.01, lower mount (radial)
Ordering information
Model / Dial size / Pressure Range / Process connection / Options
